Description

Activate Powered Cable Solutions (PCS) is offered by Remee Wire & Cable in response to the growing demand for Power over Ethernet (PoE) and other powered cabling applications requiring extended distances.  Remee’s new Activate PCS line includes a selection of standard and customized Category and hybrid copper and fiber optic cable configurations to accommodate the varying needs of both small and large cabling projects.  They can be used indoors or outdoors in commercial enterprise ethernet networks, industrial ethernet networks, and many other applications such as wireless and home or building  automation devices.

Power over Ethernet (PoE) technology allows network cables to carry electrical power to devices and nodes, such as home automation devices, VoIP phones, wireless access points, industrial controls, network switches, LED lighting systems, surveillance products, media converters, PoE injectors, plus many others, with one Ethernet cable.

PoE cables allow the installation of remote or outdoor equipment without connecting to an AC power source, and power can be delivered to more areas without the need to install an electrical infrastructure and power outlets.  Other benefits include reduced installation costs, safety, responsive deployments, easy to make changes, greater data collection capabilities and improved productivity.

However, the primary limitation of standard PoE cable is its limited distance from the hub or switch to the NIC of 100 meters (328 feet), which is the limit of the data signal, regardless of how far the power can reach.  To provide power over both PoE and extended distances,  Remee has designed Activate™, featuring a variety of Powered Cable Solutions.  The new Activate™ PCS line includes fiber optic and copper hybrid constructions which extend the signal distance much further and are compatible with a fast-growing number of devices.  Activate™ provides powered cabling for large-scale projects such as large buildings, government facilities, transportation facilities, campuses and more.

Broad Selection for Any Distance

The Activate™ PCS line includes:

  1. Category PoE Cables
    • Cat 5e for PoE (Type 1, 802.3af), carrying 15.4WPS
    • Cat 6 and Cat 6A for PoE+ (Type 2, 802.3at) cables, carrying 30WPS
    • Cat 6 Limited Power for PoE++ (types 3 and 4, 802.3bt), carrying 60WPS or 100WPS

These twisted pair Category cables include 22 AWG or 24 AWG conductors, are offered with (STP) or without (UTP) shielding, and a Polyethylene or low-smoke and flame-retardant PVC jacket.  Some are available in Siamese constructions.  Category cables are CMR (riser), CMP (plenum) or OSP rated.  The OSP rated cables feature water blocking, direct burial and messengered versions.  These cables are well suited for PoE applications requiring up to 100W of power.

  1. Composite Cable Round Hybrid Constructions

In order to activate devices needing power over distances that extend beyond the PoE limit of 100 meters (328 feet), Remee’s Activate™ solutions include round fiber optic and copper hybrid constructions.  Custom hybrid cable constructions can utilize 12 AWG to 18 AWG conductors to carry more power, while the data signal can reach greater distances than PoE by using one or more fiber optic strands.

As an example, custom Part No. 40-1200412NGB-216 includes four tight buffered/breakout fibers with water swellable aramid yarns under a sub-unit TPE jacket, and two copper cables with 16 AWG stranded bare copper conductors insulated with polyethylene.  This composite cable has an overall flame-retardant PVC jacket.  It is suitable for rugged outdoor use, including installation in a duct or aerial lashing.

  1. Siamese Hybrid Cable Constructions

Another Activate™ PCS includes Siamese hybrid cable constructions, which also allow data and power to reach beyond the PoE 100-foot distance limit.

As an example, custom Part No. 40-3300176EYO-2C18 is a Siamese construction that includes one fiber with water swellable aramid yarns under the outer jacket, and two 18 AWG stranded bare copper conductors insulated with REMGuard™ Plenum Polymer, and an overall UV-resistant REMGuard™ plenum jacket, rated CMP for indoor or outdoor use.

Standards & Certifications

Remee cables meet the applicable ETL and CSA requirements.  All Remee cable products are manufactured under ISO 9001 certification.

Modified Standard & Custom PoE and PFCS Cables

 In addition to standard cables, Remee can modify or customize any PoE cable or design any hybrid cable construction to meet your application requirements.  Remee specializes in customizing cables by adding features such as:

  • Bundled, composite and hybrid cables
  • Jacketing & insulation options (material type and wall thickness)
  • Various shielding configurations
  • Water blocking – dry or with gel
  • Messengers
  • Armoring
  • Non-standard colored jackets
  • Optional striping
  • Other requirements you may have

Standard & Other Available Security, Alarm & Control Cables

Choose from the cable options in the Part Number Table below.  Most items are in stock, but check with Remee for availability.  Part numbers link to cable spec sheets.

Important Remee Features:

  • Flexibility – Cables with stranded conductors provide high flexibility to ease installation in walls or ceilings; Remee uses only solid copper strands – no aluminum-coated copper
  • Stripability – REMGuard insulation is easy to peel or strip away from conductors
  • Interference Protection – All cables with foil shields include 100% coverage to prevent signal interference or degradation from egress or ingress
  • Water-Blocking – Water-swellable tape, water-blocking compounds or AquaLock™ dry tube technology are options at Remee to create a moisture barrier for direct burial or other applications where the cable is exposed to water or moisture
  • Bundling – Remee bundled and composite cables allow multiple signals to traverse over more than one cable under one overall jacket; this simplifies installation, with only one cable needing to be pulled for installation, rather than multiple cables
  • Jacket Options – Remee offers several jacketing options:
  • RemGuard Polymer jackets for plenum-rated cables with low flammability and low smoke
  • LSZH (Low Smoke Zero Halogen) jackets made of thermoplastic or thermoset compounds that emit limited smoke and no toxic halogen gasses
  • Ask us about other polyolefin compounds to suit your application

PoE Cable Selection Guide for Distance & Bandwidth

Remee has also created a helpful chart to assist installers and users in determining what PoE capabilities are needed for their specific application.  This useful chart displays the distance limits for various bandwidths, PoE iterations and cable types.

View and Download PoE Chart

More Information on PoE

We recommend visiting this site for more details about PoE in general:
https://www.versatek.com/what-is-power-over-ethernet/

Applications

Remee’s Activate PCS cables are suitable for a wide range of applications, including (but not limited to):

BUILDING & HOME AUTOMATION
LED LIGHTING
NETWORK SWITCHES & DEVICES
WLAN ACCESS POINTS
INDUSTRIAL CONTROLS
MEDIA CONVERTERS
PoE INJECTORS
SURVEILLANCE CAMERAS
SECURITY ACCESS CONTROLS
DIGITAL SIGNAGE
SMART CLOCKS
VoIP PHONES

Warranties
Request Product Samples

Activate™ Powered Cable Solutions – Category PoE Cables

Product Type Product Description Rating Remee Part No. & Data Sheet
Category 5e Category 5e 350MHz CMP 5BE244UTP/350
Category 5e Category 5e Shielded CMP 5BE234STP
Category 5e Category 5e 350MHz Siamese CMP 5BE244UTP350DUAL
Category 6 Category 6 550Mhz No Spline CMP 6BNS
Category 6 Category 6 Shielded 550MHz CMP 6B234STPENH
Category 6 Category 6 Dual CMP 6BE234UTPDUAL
Category 6 Category 6 550MHz (22 AWG)- Limited Power CMP-LP 6BNS224LP5
Category 6 Category 6 Enhanced 650MHz w/ Spline CMP 6B234UTPENH
Category 6a Category 6a 500MHz CMP 6UB234UTP
Category 6a Category 6a Shielded 500MHz CMP 6UB234STP
Category 5e Category 5e 350MHz CMR 5AE244UTPR
Category 5e Category 5e Shielded CMR 5AE244STP
Category 5e Category 5e 350MHz Siamese CMR 5AE244UTP/350DUAL
Category 6 Category 6 550MHz No Spline CMR 6RNS
Category 6 Category 6 Shielded 550MHz CMR 6RF234STPENH
Category 6 Category 6 Dual CMR 6RF234UTPRDUAL
Category 6 Category 6 Enhanced 650MHz w/ Spline CMR 6RF234UTPENH
Category 6a Category 6a 500MHz CMR 6UA234UTP
Category 6a Category 6a Shielded 500MHz CMR 6UA234STP
Category 5e - Direct Burial Category 5e 350MHz Water Blocking Gel PE Jacket OSP 5AEFLD
Category 5e - Direct Burial Category 5e Shielded PE Jacket OSP 5AE350STP/POLY
Category 5e - Aerial Category 5e 350 MHz Water Blocking Gel w/ Messenger PE Jacket OSP 5AEFLDMESS
Category 6 - Direct Burial Category 6a 250 MHz Water Blocking Gel PE Jacket OSP 6DBFLD234UTP
Category 6 - Aerial Category 6 Water Blocking Gel w/ Messenger PE Jacket OSP 6DBFLD234UTPMESS
Category 6 - Direct Burial Category 6 Shielded 250MHz PE Jacket OSP 6DB234STP

Activate™ Powered Cable Solutions – Custom Hybrid Cables

Product Type Product Description Rating Remee Part No. & Data Sheet
Custom Round Hybrid 40 Series Tight Buffer (4 fiber) 16/2 Unshld OSP 40-1200412NGB-216
Custom Siamese Hybrid 40 Series Tight Buffer (1 fiber SM OS2) 12/2 Unshld CMP/OFNP 40-3300176EYO-2C12
Custom Siamese Hybrid 40 Series Tight Buffer (1 fiber SM OS2) 18/2 Unshld CMP/OFNP 40-3300176EYO-2C18
Custom Siamese Hybrid 40 Series Tight Buffer (2 fiber SM OS2) 12/2 Unshld CMP/OFNP 40-3300276EYO-2C12
Custom Siamese Hybrid 40 Series Tight Buffer (2 fiber SM OS2) 18/2 Unshld CMP/OFNP 40-3300276EYO-2C18
Custom Siamese Hybrid 40 Series Tight Buffer (1 fiber OM3) 12/2 Unshld CMP/OFNP 40-3300112SAO-2C12
Custom Siamese Hybrid 40 Series Tight Buffer (1 fiber OM3) 18/2 Unshld CMP/OFNP 40-3300112SAO-2C18
Custom Siamese Hybrid 40 Series Tight Buffer (2 fiber OM3) 12/2 Unshld CMP/OFNP 40-3300212SAO-2C12
Custom Siamese Hybrid 40 Series Tight Buffer (2 fiber OM3) 18/2 Unshld CMP/OFNP 40-3300212SAO-2C18
